測量范圍
|
-50℃ -1300℃; -50℉ -1999℉
|
|
感應(yīng)器
|
K Type thermocouple
|
|
輸入
|
Single(1300), Dual (1302,1303)
|
|
分辨率
|
-50℃ + 199.9℃...0.1℃
-50℉ + 199.9℉...0.1℉
(Others-1℃/1℉)
|
|
準確度
|
-50℃to 199.9℃...0.3% rdg + 1℃
-50℉to 199.9℉...0.3% rdg + 2℉
-50℃to 1000℃... 0.5% rdg + 1℃
-50℉to 1999℉. ..0.5% rdg + 2℉
1000℃ to 1300℃..0.75% rdg + 1℃
(apply to mainframe only at 23℃±5℃)
|
|
功能
|
H Data Hold & Display ℃/℉ 選擇
0.1°/1° 分辨率選擇
T1 & T2 dual points display
T1 - T2 differential measurement
3-1/2 digit LCD
Overange: 1------
低電池指示: BT
|
|
Temperature Coefficient
|
Less than 0.1 time the applicable
accuracy specification per ℃ (℉)
|
|
輸入保護
|
熱電隅最大輸入電壓:60V DC or 24 Vrms AC
取樣率:每秒 2.5次.
|
|
操作溫度
|
0℃ - 50℃ (32℉-122℉),
0-90% R.H. (0-35℃)
|
|
電源
|
one 9V battery
|
|
尺寸
|
135mm(L)x72mm(W)x31mm(H)
|
|
重量
|
57g
|
|
附件
|
電池,使用說明書
|
|
* OPTIONAL TEMPERATURE PROBES
|
Model Range(Type K(CA) THERMOCOUPLE)
TP-K01 Bead -50℃ to 200℃/-58℉ to 392℉
General Purpose
TP-K02 Immersion -50℃ to 1000℃/-58℉ to 1832℉ Liquid or gels.
TP-K03 Surface -50℃to 750℃/-58℉ to 1382℉
|
